The AirTAC SC63X50 is a standard, double-acting tie-rod pneumatic cylinder featuring a 63mm bore size and a 50mm stroke length. Manufactured by AirTAC International Group, this components relies on compressed air to extend and retract its piston rod for linear motion control applications

• Action Type: Double-acting (uses air to extend and retract).
• Bore Diameter: 63 mm.
• Stroke Length: 50 mm.
• Port Size: 3/8" PT / BSPT thread.
• Cylinder Type: Tie-rod design.
• Magnetic Ring: None (The variant with an "S" suffix, SC63X50S, includes a built-in magnet for position sensing).
• Seal Material: Thermoplastic Polyurethane (TPU).
• Operating Temperature: Standard range is -20°C to 80°C

• Compact Body: The AirTAC SC Series features a shorter overall footprint compared to standard ISO 15552 profile cylinders with matching bore sizes.
• Advanced Piston Seal: Employs a specialized two-way heterogeneous sealing structure that incorporates built-in grease reservation for a longer operating life.
• Adjustable Cushioning: Equipped with smooth, adjustable air buffers on both ends to soften piston impact and minimize mechanical noise.
• Robust Construction: The front/rear aluminum caps and the cylinder barrel are securely locked together by high-strength structural tie rods.
