The Mean Well HDR-15-12 is a compact, ultra-slim 15W DIN rail power supply designed for industrial and automation applications. With a 12V DC output at 1.25A and a wide input range of 85–264V AC, it offers high efficiency and reliable performance. Its 17.5mm width allows for space-saving installation on TS-35/7.5 or TS-35/15 DIN rails.

Brand: Mean Well
Model: HDR-15-12
Output Voltage: 12V DC
Output Current: 1.25A
Output Power: 15W
Input Voltage Range: 85–264V AC (277V AC operational)
Input Frequency: 47–63 Hz
Efficiency: 85% (typical)
No Load Power Consumption: <0.3W
Voltage Adjustment Range: 10.8–13.8V DC
Isolation Class: Class II
Protection Features: Short circuit, overload, overvoltage
Cooling Method: Free air convection
Mounting: DIN rail TS-35/7.5 or TS-35/15
Dimensions: 17.5mm (W) × 90mm (H) × 54.5mm (D)
Operating Temperature Range: -30°C to +70°C (with derating)
Safety Approvals: UL508, UL62368-1, TUV EN61558-2-16, CE
Compliance: RoHS, LPS (Limited Power Source)
Suitable for: Industrial control panels, building automation, LED lighting systems, and other applications requiring reliable 12V DC power.

The HDR-15-12's ultra-slim design and high efficiency make it an excellent choice for space-constrained installations where reliable 12V DC power is needed.
