Key Features:

• Spring-Loaded Mechanism: Ensures consistent and reliable contact between the suction cup and workpiece, accommodating variations in height and surface irregularities.​

• Durable Construction: Crafted from robust materials to withstand demanding industrial environments, ensuring longevity and minimal maintenance.​

• Universal Compatibility: Designed to fit a wide range of suction cups and end-of-arm tooling configurations, providing flexibility across various applications.​

• Efficient Vacuum Integration: Equipped with a barbed air fitting for secure hose attachment, facilitating effective vacuum generation and maintenance.​

Applications:

• Robotic Automation: Ideal for pick-and-place operations, material handling, and assembly processes requiring precise and adaptive gripping solutions.​

• Packaging Industry: Enhances the efficiency of automated packaging lines by ensuring secure handling of products with varying shapes and sizes.​

• Manufacturing: Suitable for integration into automated systems handling components with diverse geometries and surface conditions.​

Technical Specifications:

• Material: Anodized steel and aluminum

• Barb fitting size: 5mm (3/16") OD air hose compatible ​

• Spring Travel Distance (Stroke): See Variants

• Maximum Load Capacity: 4lb​

• Compatible Suction Cup Sizes: All suctions cups with 8mm press-fit hole

• Max Panel Thickness: 12mm

• Thread Size: M12 x 1.0​

Enhance your automation capabilities with our Spring-Loaded Suction Cup Holder, engineered for reliability and versatility in dynamic industrial applications.
